Traulsen AHF232WP-FHG 2-Section Pass-Thru Heated Cabinet
Traulsen Spec-Line two-section pass-through heated holding cabinet with four full-height glass doors. 55.8 cu. ft. capacity.
Specifications
| Manufacturer | Traulsen (ITW Food Equipment Group) |
|---|---|
| Model | AHF232WP-FHG |
| Serial Number | 22E02479 |
| Type | Spec-Line Heated Holding Cabinet |
| Configuration | Pass-Through, Two-Section |
| Doors | 4 Full-Height Hinged Glass |
| Capacity | 55.8 cu. ft. |
| Shelves | 6 Adjustable Wire Shelves |
| Temperature Range | 135°F – 180°F |
| Temperature Control | INTELA-TRAUL Microprocessor with Digital Display |
| Voltage | 208-230/115V |
| Frequency | 60 Hz |
| Phase | Single Phase (1Φ) |
| Max Overcurrent Protection | 20A |
| Min Circuit Amps | 20A |
| Heater Watts | 2,000W per section (4,000W total) |
| Display Light Watts | 96W |
| Exterior Construction | Stainless Steel |
| Interior Construction | Anodized Aluminum |
| Width | 58" |
| Depth | 37-15/16" |
| Height | 83-1/4" |
| Certifications | NSF, ETL (Intertek) |
| Data Plate Date | 08/01/2020 |
| MSRP | ~$55,000 list |
| Current New Street Price | $27,000 – $31,000 |
Pickup & shipping
Pickup at our warehouse in Las Vegas, NV is free and usually available the next business day after purchase.
Local pickup preferred. Freight shipping available — contact for quote.
